Category >> สติมแทร็ป ATB-5F
รหัส : ATB-5F
ATB-5F(Steam Trap)
For Pipeline, Header etc.
Features
Large discharge amount, suitable for pipe end or large equipment.Free installation in vertical, horizontal, or lateral style1
Operate at 10°C2 below the temperature of saturated steam, prevent discharge of steam and idle operation of valve, and contribute to energy saving.
Size 32-50mm valves have removable disc and are highly air tight and durable.
Test valve can be installed on trap directly.
Specifications
| Model Name | ATB-5 | ATB-5F |
| Code name | ATB5-G | ATB5F-G |
| Type | Thermostatic | |
| Size | 15 20 25(½” ¾” 1″) | 15-50(½” ~2″) |
| Applicable pressure | Max. 1.0MPa | |
| Applicable Fluid | Saturated steam | |
| Fluid temperature | Max 184°C | |
| End conection | Screwed JIS Rc | Screwed JIS 10KFF |
| Materials | Body(Cast iron), Disc & seat (Stainless steel), Cock(Cast broze), Thermo element(Stainless steel) | |
| Allowed back pressure | Within 50% of pressure on intel side(Minimum pressure difference:0.03MPa) | |
| Pressure tightness | Steam:1.5MPa, Water:0.5MPa | |
